Quick Details

  • Type: Audio Conference System, Network Conference System, Video Conference System
  • Function: Voting
  • Simultaneous Interpretation: Yes
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: ITC
  • Model Number: TS-0200M system
  • Microphone Capacity: ≤4096
  • Channel Quantity: 32CH
  • Frequency Response: 30 ~ 2KHz
  • S.N Ratio: >75dB(A)
  • Dynamic Range: > 80dB
  • Channel Isolation: > 80dB
  • Total Harmonic Distortion: < 0.05%
  • Power Supply: AC 110V - 240V, 50Hz/60Hz
  • Audio input: LINE IN 1: 775mV (balance)
  • Certificate: C.E

Packaging & Delivery

Packaging Details Full-sealing package of Products: We adopt full-sealing bubble film+strech film+wood frame (or wood box). It will keep the moist from entering into the package to make the products rusted.
Delivery Time 7-15days

Hot selling meeting room audio systems



Product Description

System Diagram



System Feature

  • 4 kinds of conference modes: First-in-first-out/Normal/Voice Control/Application.
  • Chairman unit has the highest priority to speak.
  • 1 host could control 128 units. And if the conference needs more units, our host could do cascade with expansion host so that it could control up to 4096 units.
  • With fire signal receiving port. And if triggered, the whole system would display the fire message.
  • If you don’t want to lose your data because of break down, you could use 2 host to do backup.
  • Support protocol of CobraNet and Fiber-glass to do long distance transmission or to combine two conference room in different place.
  • The host supports communication protocol of TCP/IP and could be controlled by wireless pad, PC and mobile phone in Android.
  • With SM module, manager could send SM to every units.
  • To work with tracking camera controller to control multiple channel of tracking camera.
  • To work with conference room sound system to achieve excellent audition experience.
  • To work with 16 channel digital IR radiator host to achieve simultaneously interpretation





 Product List



1 Full Digit Conference System Host    TS-0200M  x1

2 Chairman Unit     TS-0206  x1

3 Delegate Unit     TS-0206A  xN

4 Full Digit Expansion Box for Delegate Unit     TS-0221  xN

5 16 Channel Simultaneously Interpretation Host     TS-0670H x1

6 Full Digit Interpretation Station   TS-0670HY  xN

7 IR Radiator     TS-0670HS x4

8 16 Channel IR Receiver   TS-0670HD-16  xN

9 Tracking Camera Controller     TS-0698  x1

10 Tracking Camera     TS-0695  x5

11 12 Channel Audio Mixer     TS-12P  x1

12 Professional Amplifier     TA-H4  x1

13 Pro Speaker     TS-8A  x2



Application



Main Product



Company Information

ITC Audiovisual is the pioneer of Chinese audiovisual industry. Latest, we launch Luna Cloud-based Public Address System. Also, we develop steadily. We provide our client with one-stop solution, such as conference systemvideo conferencingprofessional sound systemmultimedia central control system,IP System,Public Address System,Evacation System, etc. What's more, our system is applied to various world-class events, such as 2008 Peking Olympic Games, 2010 Shanghai Expo, 2010 Guangzhou Asian Games, etc. For now, we have up to 200 thousand successful cases in China and in worldwide.





Our products are complied with worldwide certificates:CCC,ISO9001,CE & RoHS.Parts of our product are complied with certificates:CB,SASO,ETL,UL,FCC,EN54-24.Parts of loudspeakers are certificated by waterproof,dustproof,fire-proof & explosion-proof.





By now, we have been successfully conducting both import and export activities worldwide for 10 years with suppliers and buyers.
